Prakriti Appliances offers eco-friendly, energy-efficient solutions designed to enhance comfort while minimizing environmental impact.
Number
Location
| S. No | Particulars / Specifications | Classic |
|---|---|---|
| 1 | Fan Motor | BLDC Technology Motor |
| 2 | Sweep | 1200MM (48″) |
| 3 | BEE / BIS | Yes |
| 4 | PCB Type | RF |
| 5 | Remote Features | Booster, Reverse, Sleep Mode & Timer |
| 6 | Shackle | With Earthing Symbol |
| 7 | Stator | 12mm thick CRCA HI-PERM 18 Slot |
| 8 | Winding Material | 100% Copper |
| 9 | Rotor | 16 Pole Magnetic Ring |
| 10 | No. of Bearings | Two ball bearings |
| 11 | No. of Blades | 3 |
| 12 | Type of Blade | Aluminium |
| 13 | Down Rod | 10″ |
| 14 | Top Cover | Aluminium |
| 15 | Bottom Cover | Aluminium |
| 16 | Rated Air Delivery | 210-215 CMM |
| 17 | Rated Service Value | > 6.5 CMM/Watt |
| 18 | Rated Power | 32-35 W |
| 19 | Rated Current | 0.15 A |
| 20 | Rated Speed | 350-380 RPM |
| 21 | Power Factor | >0.9 |
| 22 | Rated Frequency | 50 Hz |
| 23 | THD | < 20 |
| 24 | Class of Motor Winding | CLASS “B” |
| 25 | PCB Surge Capacity | 4 KV |
| 26 | Rated Voltage | 220-240 Volts, 50 Hz, Single Phase A.C. |
| 27 | Test Voltage | 230 Volts, 50 Hz, Single Phase A.C. |
| 28 | Safe Operating Voltage | 100-300 Volts |
| 29 | Finish | Powder Coated |
| 30 | Available Colours | White, Brown, Matt Black, Ivory |
| 31 | Weight of Fan (Gross) | 4.0 Kg |
| 32 | Tolerance of Performance | As per IS 374 |
